S50Maximum Output

Built for operations that need maximum power and zero downtime. Aerospace, heavy fabrication, high-volume industrial marking — the S50 delivers where it matters.

50W

High-duty cycle

99.8%

Light yield

10h

Battery runtime

Book a Demo →
Rugged red and black tablet device with carrying case and data display screen for field testing and diagnostics

KEY FEATURES

High-Duty-Cycle 50W Laser

Engineered for continuous operation in demanding production environments. Second-generation fibre laser generator with 99.8% actual light yield. Runs cool even under sustained full-power marking loads.

Laser Cleaning & Welding

The S50 does more than mark. Full industrial laser cleaning removes rust, oxides, coatings, and contaminants. Laser welding capability for precision joining — one machine, three applications.

Built for Heavy Manufacturing

Designed for aerospace suppliers, metal fabrication shops, and high-volume industrial lines. ±0.01mm repeatable positioning accuracy. Scales to your line speed without compromising quality.

10-Hour Heavy-Duty Battery

The S50's optional 324Wh lithium battery rig supports 10+ hours of continuous full-power operation. Advanced heat-dissipation duct system prevents thermal build-up even under sustained marking loads.

BATTERY OPTION

10-hour heavy-duty battery rig

The most powerful battery option in the range. 324Wh capacity with advanced heat-dissipation ducting keeps the S50 at full power for an entire extended shift. The duct system actively manages thermal load so marking quality never degrades — even during continuous high-output operation.

324Wh

Capacity

10h+

Full-power runtime

Rugged red and black tablet device with carrying case and data display screen for field testing and diagnostics

TECHNICAL SPECIFICATIONS

Laser typeFibre laser generator (2nd generation)
Output power50W — high-duty cycle
Laser wavelength1064 nm
Marking speed≤ 7,000 mm/s
Marking range70×70 / 100×100 / 145×145 mm
Line width0.03 mm
Positioning accuracy±0.01 mm
Control system8-core Linux, 8-inch bonded LCD
Light yield99.8% actual
Power supply110V/220V AC or 324Wh 15Ah battery
Power consumption≤ 250W
Total weight8 kg (plug-in) / 8.8 kg (battery)
Operating temperature0–40 °C
Barcode formatsCODE39, CODE128, QR Code
File formatsBMP, DXF, HPGL, JPEG, PLT, XLSX
ComplianceGB7247-87, GB10320-88, ISO9000-3, IEC536

What's in the box: S50 laser unit, handheld lens module, focal length spacer set, accessory bag, power cord/adapter, user manual, warranty card, certificate of conformity, and packing list — all included.

READY FOR MAXIMUM OUTPUT?

Built for operations that can't afford downtime. See the S50 in action on your own parts.
